EXACKT (Extender over AC Kit)
The EXACKT is an HDMI extender that uses the AC wiring as a medium to transmit HDMI signals that have been converted to H.265 from the TX to the RX. This is a"plug and play" solution. Simply plug the HDMI source into the TX and plug it into the AC outlet, then connect the RX to the display and plug it into the AC outlet, done! The EXACKT also includes an IR receiver and blaster to transmit IR signals from the display (RX end) back the the TX end for source control. You can use up to two extra RX devices for a total of three. The part number is EXAC DEC.
Primary Use: Extending HDMI AV signals over existing AC wiring when traditional Category Cable is not an option or convenient.
Features & Benefits:
Plug and Play operation
Up to 3 RX devices can be used with TX
HDMI 1.3 (6.75Gbps), HDCP 1.4 compliant
Video resolutions up to 1080p
LPCM Stereo (32kHz., 44.1kHz., & 48kHz.
HDMI "loop through" to extend existing HDMI circuit to another display
Infrared control signal is transmitted together with the HDMI signal (from RX to TX)
Supports 480i/480p/720p/1080i/1080p/1400x1050 resolutions
Transmission distance:
70m/ 232 ft.:
3-Year Warranty
HDMI Compliance HDMI 1.3 HDCP Compliance HDCP 1.4 Video Bandwidth 6.75 Gbps Video Resolution Up to 1080p Color Space RGB / YCbCr 4:4:4, YCbCr 4:2:2/4:2:0, YUV 4:4:4 Color Depth 8/10/12-bit HDMI Audio Formats LPCM 2.0 32kHz., 44.1kHz., & 48kHz. ESD Protection Human body model - ±8kV (Air-gap discharge) ±4kV (Contact discharge)
